Specifications
General | |
Frequency coverage*1 U.S.A. Version RX TX | 0.030– 60.000 MHz*2 1.800– 1.999 MHz 3.500 – 3.999 MHz 5.255 – 5.405 MHz*2 7.000 – 7.300 MHz 10.100–10.150 MHz 14.000– 14.350 MHz 18.068–18.168 MHz 21.000– 21.450 MHz 24.890–24.990 MHz 28.000– 29.700 MHz 50.000–54.000 MHz*1 Frequency ranges vary depending on version. *2 Some frequency ranges are not guaranteed. |
Mode | USB, LSB, CW, RTTY, PSK31/63, AM, FM |
Number of channels | 101 (99 regular, 2 scan edges) |
Antenna connector | SO-239×4 and BNC×2 (50Ω unbalanced (Tuner off)) |
Power supply requirement: | 85–265V AC |
Temperature range | 0°C to +50°C; +32°F to +122°F |
Frequency stability | Less than ±0.05ppm(0°C to +50°C @ 54MHz, after warm up) |
Frequency resolution | 1Hz (minimum) |
Power supply requirement | 85–265V AC |
Power supply requirement | Tx Max. power: 800VA Rx Stand-by: 200VA (typ.) Max. audio: 210VA (typ.) |
Dimensions | 425×149×435 mm; 16.73×5.87×17.13 in |
Weight | 23.5 kg; 51.8 lb |
Transmitter | |
Output power SSB, CW, RTTY, PSK31, FM AM Transverter Connector, CW | (continuously adjustable) 5–200W 5–50W More than –20dBm |
Modulation system SSB AM FM | Digital P.S.N. modulation Digital low power modulation Digital phase modulation |
Spurious emission | More than 60dB (HF bands) More than 70dB (50 MHz band) |
Carrier suppression | More than 63dB |
Unwanted sidebandr suppression | More than 70dB |
δTX variable range | ±9.999 kHz |
Microphone impedance | 600Ω (8-pin connector) |
Receiver | |
Receive system | Double conversion super-heterodyne system |
Intermediate frequencies Main receiver:Sub receiver: | 64.455MHz/36kHz (1st/2nd)64.555MHz/36kHz (1st/2nd) |
Sensitivity (typical) SSB, CW, RTTY, PSK31, FM 0.1–1.799 MHz 1.8–29.999 MHz 50.0–54.0 MHz AM 0.1–1.799 MHz 1.8–29.999 MHz 50.0–54.0 MHz FM 28–29.999 MHz 50.0–54.0 MHz | (BW: 2.4 kHz at 10dB S/N) 0.5μV 0.16μV 0.13μV (BW: 6 kHz at 10dB S/N) 6.3μV 2μV 1μV (BW: 15 kHz at 12dB SINAD) 0.5μV 0.32μV |
Squelch sensitivity (Pre-amp: OFF) SSB, CW, RTTY, PSK FM | Less than 5.6μV Less than 1μV |
Selectivity (representative value) SSB (BW: 2.4 kHz, sharp)CW, RTTY, PSK (BW: 500 Hz, sharp)AM (BW=6KHz) | FM (BW: 15 kHz)More than 2.4 kHz/–3dB Less than 3.6 kHz/–60dB More than 500 Hz/–3dB Less than 700 Hz/–60dB More than 6.0 kHz/–3dB Less than 15.0 kHz/–60dB More than 12.0 kHz/–6dB Less than 20.0 kHz/–60dBSpurious and image rejection ratioMore than 70dBAudio output powerMore than 2.6W at 10% distortion with an 8Ω loadRIT variable range±9.999kHz |
Antenna Tuner | |
Matching impedance range | HF bands: 16.7Ω to 150Ω unbalanced (VSWR better than 3:1) 50MHz: 20Ω to 125Ω unbalanced (VSWR better than 2.5:1) |
Minimum operating power | HF bands: 8W 50MHz band: 15W |
Tuning accuracy | VSWR 1.5:1 or less |
Insertion loss | Less than 1.0 dB (after tuning) |
All stated specifications are subject to change without notice or obligation.
